VIBXPERT II

Portable Vibration Data Analyser

The VIBXPERT® II is a versatile portable vibration data collector and signal analyser based on sophisticated and refined technology.

The VIBXPERT II is a high performance, fully featured FFT data collector and signal analyser which allows easy condition monitoring of equipment found in many industries such as power generation, petrochemical and pulp and paper. The VIBXPERT II collects field data including vibration information, bearing condition, inspection and process data. Extensive analysis functions facilitate data analysis and condition diagnostics on site.

  • Easy to use – Intuitive operation, handy design & brilliant colour display
  • One & two plane field balancing – Identify & repair unbalance of rotors
  • Fast data collection – Optimised measuring workflows & advanced processor technology
  • Vibration analysis – Powerful analysis & diagnostic tools for machine troubleshooting
  • Longevity – Long battery life & a large flash based data storage
  • Two true synchronous channel capabilities – For diagnosis of complex machinery faults
  • High quality – Replaceable compact flash cards, dust & splash proof (IP65)
  • High resolution – 102,400 lines of resolution
